Gigabyte B860 DS3H WIFI6E ATX LGA1851 Motherboard – Specifications
Key Features:
Socket: LGA 1851 (Intel® Core™ Ultra Series 1 & 2)
Chipset: Intel B860
Memory: 4 x DDR5 DIMM slots (up to 256GB, 9066 MHz)
Expansion Slots: 1 x PCIe 5.0 x16, 4 x PCIe 4.0 x1
Storage:
2 x M.2 slots (1 x PCIe 5.0, 1 x PCIe 4.0)
4 x SATA III ports (RAID 0, 1, 5, 10 support)
Networking & Connectivity:
LAN: 2.5Gb Ethernet (Realtek RTL8125)
Wi-Fi: Wi-Fi 6E (802.11ax) + Bluetooth 5.3
Rear I/O Ports:
1 x USB 3.2 Gen 2x2 Type-C
1 x USB 3.2 Gen 2 Type-A
4 x USB 2.0 Type-A
1 x HDMI 2.1, 1 x DisplayPort 2.1
1 x 2.5GbE RJ-45 port
3 x 3.5mm audio jacks
2 x Wi-Fi antenna connectors
Internal Features:
Power Delivery: 8+1+2 phase VRM design
Cooling: Large heat sinks + M.2 Thermal Guard
RGB Support: 4 x RGB LED headers
EZ-Latch: Tool-less PCIe & M.2 installation
Audio:
Realtek ALC897 7.1-channel HD audio
Form Factor & Weight:
Size: ATX (305 x 244 mm)
Weight: Approx. 1.2 kg
